$129,900.00

Additional Information

Manufacturer

XL Specialized

Year

2021

Share this out

DISCLAIMER: Price quoted does not include any freight or delivery charges. Specifications are believed to be correct but may contain errors and/or omissions. Pictures are representative and may not be identical. Description and Images © West-Mark

2021 XL SPECIALIZED 110HDG 18″ DH HYDRAULIC FLIP AXLE AND FLIP NECK For Sale In Ceres, California

SKU: 2021 XL SPECIALIZED 110HDG 18" DH HYDRAULIC FLIP AXLE AND FLIP NECK For Sale In Ceres, California Categories: ,

Description

2021 XL Specialized 110 Low Profile HDG With Motor Mounted in Gooseneck

CAPACITY
Capacity: 110,000 Lb Overall
Concentrated: 110,000 Lb In 12’

OVERALL LENGTH & WIDTH
Overall Length: 54’
Overall Width: 8’6′

GOOSENECK
Low-Profile Style Neck With Relief Cut-Out
13HP Honda Unit in Neck Base w/Steel Cover & Dual Hydraulics
51” 5th Wheel Height
5 Position Variable Ride Height
110” & 84” Swing Clearance
Hydraulics Run Off Wet Kit
Air Operated Lock With Manual Safety Latch
Work Light
36″ Flip Neck Extension

MAIN DECK
29’ Long
T-1 Flange, 80K Web
(4) 16” Fabricated I-Beams
18” Loaded Deck Height
6” Ground Clearance
10” & 4” Stubbed Jr. I-Beams On Alternating 12” Centers
31” Front Flip Ramps
7 Bent D-Rings Per Side
1 3/4” Apitong Decking – Raised, Open Center
Toolbox on GN on Driver side
4 Flat D-Rings In Toolbox
13 Chain Drops Per Side
Heavy-Duty Swing Out Outriggers On 24” Centers
Heavy-Duty Flatback Outriggers, Front And Center
2 Flag Holders
Bucket Well At Rear, Plate On Bottom
4 Flat D-Rings In Bucket Well
Front Ramp Upper Flange Reinforcement

REAR BRIDGE
15′ Long
Rear Transition With 32° Slope
40” Loaded Deck Height
Covered Wheels
Open Boom Trough – Bolt-on Bottom Plate
2 Flat D-Rings On Main Beams At Rear
2 Chain Drops On Each Bolster
2 Flag Holders
2 Stake Pockets In Tail Channel for Wide Load Sign
Frame Reinforcement For Booster

SUSPENSION
25,000 LB Air Ride
Raise And Lower Valve
Manual Ride Height Control
Liquid Filled Air Gauge

AXLES
(3) 25,000 Lb Nominal
Air Lift On 3rd Axle
Hub Pilot, Outboard Drums
16 1/2” X 7” Brakes
Auto Slack Adjusters
60” Axle Spacing
Limit Chains On All Axles
Spring Brakes On 1 Axle
ABS Not Required

WHEELS & TIRES
8.25 X 22.5 Rims
275 / 70R / 22.5 Tires
All Aluminum/Outside/Inside

LIGHTING
4″ Amber Strobe Tail Light
12V Sealed Grote Harness
Rubber Mounted LED Lights
2 Tail Light Package With
Aluminum Cover
2 Clearance Lights Per Side
1 Mid-Turn Light Per Side
7 Pole Electric Socket

Hydraulic Flip Axle

PAINT
Black

Quantity – 1
Year – 2021
Manufacturer – XL SPECIALIZED
Model – 110HDG 18″ DH HYDRAULIC FLIP AXLE AND FLIP NECK
Condition – Used
Length – 54 ft Well Length – 29 ft
Type of Neck – Gooseneck Detachable Removable
Gooseneck Type – Hydraulic Pony
Motor – Yes
Multi-Position King Pin – Yes
Toolbox – Yes Outriggers – Yes
Bucket Well – Yes
Adjustable Ride Height – Yes
Flip Axle – Yes Number of Flip Axles – 1
Number of Lift Axles – 1
Flip Axle Only – Yes

Now Available
